3PC Flanged Ball Valve with Pneumatic Actuator PN40

Features:
PRESSURE: PN40
FACE-TO-FACE DIMENSIONS: GB/T12221-1989
FLANGE END DIMENSIONS: GB/9113
DESIGN: GB/T12237-1989
TEST: GB/T13927-1992
MATERIAL STANDARD: S45C/ASTM A216 GR-WCB/DIN1.00619
SS316/ASTM A351 GR-CF8M/DIN1.4408
SS304/ASTM A351 GR-CF8/DIN1.4308

3PC Flanged Ball Valve PN16

Features:
PRESSURE: PN16
FACE-TO-FACE DIMENSIONS: GB/T12221-1989
FLANGE END DIMENSIONS: GB/9113
DESIGN: GB/T12237-1989
TEST: GB/T13927-1992
MATERIAL STANDARD: S45C/ASTM A216 GR-WCB/DIN1.00619
SS316/ASTM A351 GR-CF8M/DIN1.4408
SS304/ASTM A351 GR-CF8/DIN1.4308

3PC Flanged Ball Valve with ISO5211 Direct Mounting Pad PN40

Features:
PRESSURE: PN40
FACE-TO-FACE DIMENSIONS: GB/T12221-1989
FLANGE END DIMENSIONS: GB/9113
DESIGN: GB/T12237-1989
TEST: GB/T13927-1992
MATERIAL STANDARD: S45C/ASTM A216 GR-WCB/DIN1.00619
SS316/ASTM A351 GR-CF8M/DIN1.4408
SS304/ASTM A351 GR-CF8/DIN1.4308

ANSI Standard 2-PC Flanged Ball Valve Class 150/300LB

Features:
DESIGN: ANSI 16.34
FACE-TO-FACE DIMENSIONS: DIN3202 F4/F5
FLANGE END DIMENSIONS: DIN2633 PN16
TEST: API 598
MATERIAL: CARBON STEEL WCB/DIN1.0619
STAINLESS STEEL 304/1.4308
STAINLESS STEEL 316/1.4408

ANSI Standard 2-PC Flanged Ball Valve with Pneumatic Actuator and Limit Switch

Features:
DESIGN: ANSI 16.34
FACE-TO-FACE DIMENSIONS: DIN3202 F4/F5
FLANGE END DIMENSIONS: DIN2633 PN16
TEST: API 598
MATERIAL: CARBON STEEL WCB/DIN1.0619
STAINLESS STEEL 304/1.4308
STAINLESS STEEL 316/1.4408

Q71f Wafer Flanged Thin Ball Valve

Features:
PRESSURE: PN16
FACE-TO-FACE: GB/T12221-1989
FLANGE END DIMENSIONS: GB/T9113
DESIGN: GB/T12237-1989
TEST: GB/T13927-1992
MATERIAL STANDARD: S45C/ASTM A216 GR-WCB/DIN1.00619
SS316/ASTM A351 GR-CF8M/DIN1.4408
SS304/ASTM A351 GR-CF8/DIN1.4308

3PC DIN Flanged Ball Valve PN40

Features:

Face-to-face dimension: DIN3202-F1

Flanged connection: PN16/PN40 DIN2633

TEMPERATURE RANGE: -20oC~150oC

SUITABLE MEDIUM: WATER, OIL, AIR AND SOME CORROSIVE LIQUID

INVESTMENT CASTING BODY

DESIGN: 1/2"~2" PN40

TEST: API 598

MATERIAL: CARBON STEEL WCB/DIN1.0619

STAINLESS STEEL 304/1.4308

STAINLESS STEEL 316/1.4408

3PC DIN Flanged Ball Valve with ISO5211 Direct Mounting Pad PN16

Features:

Face-to-face dimension: DIN3202-F1

Flanged connection: PN16/PN40 DIN2633

TEMPERATURE RANGE: -20oC~150oC

SUITABLE MEDIUM: WATER, OIL, AIR AND SOME CORROSIVE LIQUID

INVESTMENT CASTING BODY

DESIGN: 1/2"~6" PN40

TEST: API 598

MATERIAL: CARBON STEEL WCB/DIN1.0619

STAINLESS STEEL 304/1.4308

STAINLESS STEEL 316/1.4408

JIS10K 20K Flanged 2-PC Ball Valve

Features:
PRESSURE RANGE: 10K
FACE-TO-FACE DIMENSIONS: JIS 2002-2000
FLANGE END DIMENSIONS: JIS B2212-1999
DESIGN: ANSI 16.34
TEST: GB/T13927-1992
MATERIAL STANDARD: S45C/ASTM A216 GR-WCB/DIN1.00619
SS316/ASTM A351 GR-CF8M/DIN1.4408
SS304/ASTM A351 GR-CF8/DIN1.4308

GB 2PC Flanged Ball Valve with ISO5211 Direct Mounting Pad PN16

Features:
FACE-TO-FACE: GB/T12221-1989
FLANGE END DIMENSIONS: GB/T9113.1-2000
DESIGN: GB/T12237-1989
TEST: GB/T13927-1992
INVESTMENT CASTING BODY
MATERIAL STANDARD: S45C/ASTM A216 GR-WCB/DIN1.00619
SS316/ASTM A351 GR-CF8M/DIN1.4408
SS304/ASTM A351 GR-CF8/DIN1.4308

GB 2PC Flanged Ball Valve with Pneumatic Actuator PN16

Features:
FACE-TO-FACE: GB/T12221-1989
FLANGE END DIMENSIONS: GB/T9113.1-2000
DESIGN: GB/T12237-1989
TEST: GB/T13927-1992
INVESTMENT CASTING BODY
MATERIAL STANDARD: S45C/ASTM A216 GR-WCB/DIN1.00619
SS316/ASTM A351 GR-CF8M/DIN1.4408
SS304/ASTM A351 GR-CF8/DIN1.4308

GB 2PC Flanged Ball Valve with Pneumatic Actuator PN16

Features:
FACE-TO-FACE: GB/T12221-1989
FLANGE END DIMENSIONS: GB/T9113.1-2000
DESIGN: GB/T12237-1989
TEST: GB/T13927-1992
INVESTMENT CASTING BODY
MATERIAL STANDARD: S45C/ASTM A216 GR-WCB/DIN1.00619
SS316/ASTM A351 GR-CF8M/DIN1.4408
SS304/ASTM A351 GR-CF8/DIN1.4308

2PC DIN Flanged Ball Valve PN40/16

Features:
DESIGN: ANSI 16.34
FACE-TO-FACE DIMENSIONS: DIN3202 F4/F5
FLANGE END DIMENSIONS: DIN2633 PN16
TEST: API 598
MATERIAL: CARBON STEEL WCB/DIN1.0619
STAINLESS STEEL 304/1.4308
STAINLESS STEEL 316/1.4408

Stainless Steel Threaded Mini Ball Valve F/F

Product features
Blow-out proof stem design
Entirely silica sol precision forging
Reduced port
Handle operated
Specification:1/4"-1"
Material:SS304 SS316
Pressure:1000WOG/PSI PN63
Seat material:PTFE RPTFE

Stainless Steel Threaded Mini Ball Valve M/M

Product features
Blow-out proof stem design
Entirely silica sol precision forging
Reduced port
Handle operated
Specification:1/4"-1"
Material:SS304 SS316
Pressure:1000WOG/PSI PN63
Seat material:PTFE RPTFE
